Huawei h12-811-v1-0 practice test

HCIA-Datacom V1.0 Exam


Question 1

The administrator cannot log in to the Huawei router through Telnett, but other administrators can
log in normally, so which of the following are the possible reasons? ()*

  • A. The authority level of the administrator user account has been modified to 0 365/366 Questions & Answers PDF P-
  • B. The administrator user account has been disabled
  • C. The Te1net service of the AR2200 router has been disabled
  • D. The administrator user account has been deleted
Answer:

B, D

Explanation:
366/366

Discussions

Question 2

There are hosts in a private network that need to access 1nternet. In order to achieve this
requirement, which of the following configurations should be done by the administrator on the edge
router of the network? ()*

  • A. Default route
  • B. STP
  • C. DHCP
  • D. NAT
Answer:

A, D

Discussions

Question 3

When deploying ACL on Huawei equipment, which of the following descriptions is correct is ().*

  • A. ACL can match the TCP/UDP port number of the packet, and can specify the range of port numbers 364/366 Questions & Answers PDF P-
  • B. The same ACL can be called under multiple interfaces
  • C. When ACL defines rules, it can only proceed in the order of 10, 20, 30
  • D. ACL cannot be used to filter OSPF traffic, because OSPF traffic does not use UDP protocol encapsulation
  • E. When calling ACL under the interface, it can only be applied to the outbound direction
Answer:

A, B

Discussions

Question 4

The router Radius information configuration is shown in the figure. Which of the following
#Radius-server template Huawei radius-server shared.key cipher
statements are correct?
Huawei radius-server authentication 200.0.12.1 1812 radius-server accounting 200.0.12.1 1813#*

  • A. The source IP address of the Radius packet sent by the router is 200.0.12.2
  • B. The P address of the accounting server is 200.0.12.1
  • C. The P address of the authorization server is 200.0.12.1
  • D. The P address of the authentication server is 200.0.12.1
Answer:

B, C, D

Discussions

Question 5

Link aggregation is a common technology in enterprise networks. Which of the following
descriptions are the advantages of link aggregation technology? ()
363/366
Questions & Answers PDF
P-

  • A. Improve safety
  • B. Achieve load sharing
  • C. Increase bandwidth
  • D. Improve reliability
Answer:

B, C, D

Discussions

Question 6

Which of the following features does the default VLAN in the Layer 2 Ethernet switch have? ()*

  • A. The default VLAN cannot be deleted manually
  • B. By default, all ports of the switch are member ports of the default VLAN
  • C. A default VLAN must be created before it can be assigned a port
  • D. The P address configured on the switch will only be applied to the member ports of the default VLAN
Answer:

A, B

Discussions

Question 7

362/366
Questions & Answers PDF
P-
ip route-static.10.0.2.2255.255.255.25510.0.12.2 preference20, the correct statement about this
command is ()

  • A. The NextHop of this route is 10.0.12.2
  • B. The priority of this route is 20
  • C. This route can guide the forwarding of packets with the destination P address of 10.0.2.2.
  • D. This route can guide the forwarding of packets with the destination IP address 10.0.12.2
Answer:

A, B, C

Discussions

Question 8

In the OSPF protocol, the correct one in the following description of DR is (). ()*

  • A. Establish an adjacency relationship between DR and BDR
  • B. If the priority values of the two routers are equal, the router with the larger Router ID is selected as the DR
  • C. By default, all routers in this broadcast network will participate in the DR election
  • D. If the priority values of the two routers are different, the router with the smaller priority value is selected as the DR
Answer:

A, B, C

Discussions

Question 9

How to add AP on AC.? ()*

  • A. Add online
  • B. Automatically discover AP
  • C. Import AP offline
  • D. Manually confirm APs in the non-certified list
Answer:

A, B, C

Discussions

Question 10

The administrator cannot log in to the Huawei router through Telnet, but other administrators can
log in normally. What are the possible reasons for the following items? ()

  • A. The administrator user account has been deleted
  • B. The administrator user account has been disabled
  • C. The Telnet service of the AR2200 router has been disabled
  • D. The authority level of the administrator user account has been modified to 0
Answer:

A, B

Explanation:
361/366
Questions & Answers PDF
P-

Discussions
