F5-Networks 101 practice test

Application Delivery Fundamentals Exam


Question 1


An administrator sets up a web server for a new web application. The administrator cannot access
the web server at is causing this issue?

  • A. The HTTP service only listens on localhost
  • B. The users IP needs to be allowed to access
  • C. The server needs to be restarted
  • D. The HTTPS service Is not running
Answer:

A

Discussions

Question 2

An administrator connects two devices using an Ethernet cable. The link fails to come up on either
device, which setting could prevent the link from being established?

  • A. Proxy settings
  • B. IP configuration
  • C. Link speed
  • D. DNS resolvers
Answer:

C

Discussions

Question 3

An IPV6 clients tries to connect to
http://myserver.com
Wh.cn type of DNS request should the client send to its configured server?

  • A. type MX
  • B. type AAAA
  • C. type NS
  • D. type A
Answer:

B

Discussions

Question 4

An administrator configures a custom MAC masquerade address on a redundant BIG-IP system
What will be the result?
A. The administrator will be prompted during configuration to define which until will use the MAC
masquerade address
B. The MAC masquerade address will be concurrently used by both active and standby unit
C. The MAC masquerade address will only be used by the active unit. The standby unit in use the
system's actual interfaces (s) MAC address
D. The MAC masquerade address will only be used by the un.t with higher unit ID The other unit wilt
use the system's actual interface(s) MACaddress

Answer:

C
//support.f5.com/cp/article/K13502

Discussions

Question 5

A user fails to provide credentials when requesting a web resource that requires authentication.
Which HTTP response code does the server send?
A. HTTP 200
B. HTTP 302
C. HTTP 401
D. HTTP 502

Answer:

C
//httpstatuses.com/401

Discussions

Question 6

Exhibit.

the Web application Server made a query to the Database to present dynamic content for a user who
would be the client?

  • A. The User
  • B. The Big-IP
  • C. The Database
  • D. The Web application server
Answer:

D

Discussions

Question 7

A BIG-IP Administrator has a cluster of devices.
What should the administrator do after creating a new Virtual Server on device 1?

  • A. synchronize the settings of device 1 to the group
  • B. create a new cluster on device 1
  • C. create the new virtual server on device 2
  • D. synchronize the settings of the group to device 1
Answer:

A

Discussions

Question 8

An administrator suspects that a BIG IP appliance is experiencing performing issue due to spikes in
CPU usage checks the performance issues does to spikes in CPU usage checks the performance
report in the BIG-IP UI on CPU spikes are evident in the graphs. Which section in the BIG IP UI can the
administrator check to troubleshoot the issue further?

  • A. Statistics > Utilization
  • B. System . Utilization
  • C. Statics > Dashboard
  • D. System > Services
Answer:

C

Discussions

Question 9

An application has a mix of both and short and long lived connections. Which algorithm would
provide and event distribution of all connections across the pool?

  • A. Priority group activate
  • B. Least connections
  • C. Static ration
  • D. Round robin
Answer:

B

Discussions

Question 10

For an IP of 192 168 10.10 with a subnet mask of 255 255.240 0 an administrator is asked to provide
The first network address
The broadcast address, and
The number of hosts available per subnet host
What should be the administrator's response'?

  • A. 192. 168. 0. 1 is the network address. 192.168.10 255 is the broadcast address. There are 16382 addressable hosts
  • B. 192. 168. 0. 0 is the network address 192 168 15 255 is the broadcast address. There are 4094 addressable hosts
  • C. 192.168. 0.0 is the network address. 192 168 16 255 is the broadcast address. There are 1022 addressable hosts
  • D. 192. 168.16. 0 is the network address, 192 168 31 255 is the broadcast address. There are 409J addressable hosts
Answer:

B

Discussions
