cisco 600-212 practice test

Implementing Cisco Service Provider Mobility LTE Networks (SPLTE)


Question 1

Which application protocol is used by the SWx reference point?

  • A. RADIUS
  • B. Diameter
  • C. TCP
  • D. GTPv2
Answer:

B

Discussions

Question 2

Which Cisco ASR 5000 configuration option allows you to configure Lawful Intercept on all MMEs?

  • A. context li_context administrator li encrypted password 6e76e79ab2296d70 li-administration interface interface_to_dfvendor ip address 10.10.10.2 255.255.255.0 lawful-intercept src-ip-addr 10.10.10.2 lawful-intercept tcp event-delivery dest-addr 10.20.20.1 dest-port 8081 lawful-intercept tcp content-delivery dest-addr 10.20.20.2 dest-port 8082
  • B. context li_context administrator li encrypted password 6e76e79ab2296d70 li-administration interface interface_to_dfvendor ip address 10.10.10.2 255.255.255.0 lawful-intercept src-ip-addr 10.10.10.2 lawful-intercept tcp content-delivery none lawful-intercept tcp event-delivery dest-addr 10.20.20.1 dest-port 8081 require lawful-intercept-tcp-proxy multiple
  • C. context li_context administrator li encrypted password 6e76e79ab2296d70 li-administration interface interface_to_dfvendor ip address 10.10.10.2 255.255.255.0 lawful-intercept src-ip-addr 10.10.10.2 lawful-intercept tcp event-delivery dest-addr 10.20.20.1 dest-port 8081 require lawful-intercept-tcp-proxy multiple
  • D. context li_context administrator li encrypted password 6e76e79ab2296d70 li-administration interface interface_to_dfvendor ip address 10.10.10.2 255.255.255.0 lawful-intercept src-ip-addr 10.10.10.2 lawful-intercept tcp content-delivery dest-addr 10.20.20.2 dest-port 8082 require lawful-intercept-tcp-proxy multiple
Answer:

B

Discussions

Question 3

Which types can be classified as bulk stats on the Cisco ASR 5000?

  • A. Counter, Gauge, Information
  • B. Gauge, Counter, Iterative
  • C. Circular, Gauge, Counter
  • D. Watermark, Counter, Gauge
Answer:

A

Discussions

Question 4

Which network function converts Voice over LTE voice bearer to PSTN voice bearer?

  • A. border gateway control function
  • B. media gateway function
  • C. multimedia resource function
  • D. session border controller function
Answer:

B

Discussions

Question 5

Which option describes the flow of the S6a configuration on the Cisco ASR 5000 system?

  • A. MME-service, hss-peer-service, diameter endpoint, peer configuration
  • B. MME-service, diameter endpoint, hss-peer-service, peer configuration
  • C. MME-service, diameter endpoint, S6a-service, peer configuration
  • D. s6a-service, hss-peer-service, diameter endpoint, peer configuration
Answer:

A

Discussions

Question 6

Which function does the Cisco Serving Gateway perform in a basic EPC network?

  • A. The SGW is responsible for authentication of the subscribers connecting to EPC network.
  • B. The SGW is a termination point in the network for Internet access.
  • C. The SGW forwards data packets from subscribers toward the PDN gateway.
  • D. The SGW is responsible for assigning the IP address to the subscriber.
Answer:

C

Discussions

Question 7

Which 3GPP specification describes charging management, charging architecture, and principles?

  • A. 3GPP-TS-32.240
  • B. 3GPP-TS-32.295
  • C. 3GPP-TS-32.297
  • D. 3GPP-TS-32.299
Answer:

A

Discussions

Question 8

Which option describes local-user accounts on the Cisco ASR 5000?

  • A. The local-user account is ANSI T1.276-2003 compliant.
  • B. The local-user account can be configured only in the local context.
  • C. The local-user account allows for privilege-level escalation on a context level.
  • D. The local-user account can be accessed only from the serial port.
Answer:

A

Discussions

Question 9

Which three IEs are supported in Downlink Data Notification as it relates to the Cisco Serving Gateway? (Choose three.)

  • A. cause
  • B. EPS bearer ID
  • C. ARP
  • D. recovery
  • E. originating node
  • F. bearer contexts
Answer:

A B C

Discussions

Question 10

Which two radio technologies are used in LTE? (Choose two.)

  • A. OFDMA
  • B. MIMO
  • C. TDMA
  • D. EV-DO
  • E. VOR
  • F. DME
Answer:

A B

Discussions
To page 2
