cisco 500-601 practice test

Application Centric Infrastructure Support Representative

page 1 out of 4

Viewing questions 1-15 out of 50


Question 1

Which command is used to successfully SSH into a Cisco ARC or switch CLI using a remote authentication server?

Answer:

C

Discussions
0 / 1000

Question 2

Which two statements about Cisco ACI interaction with STP in legacy networks are true? (Choose two)

  • A. External switches ignore flooded BPDU frames received from the Cisco ACI fabric.
  • B. BPDU guard is enabled on FEX ports by default.
  • C. BPDU guard cannot be configured on leaf edge ports.
  • D. STP is enabled by default within the Cisco ACI fabric.
  • E. BPDU frame is flooded within EPG No configuration is required.
Answer:

A D

Discussions
0 / 1000

Question 3

Where does the subnet address of the distributed gateway need to be configured when route leaking is required?

  • A. under the contract provider EPG
  • B. under the contract consumer EPG
  • C. in a shared bridge domain in the tenant common
  • D. in the endpoint bridge domain
Answer:

D

Discussions
0 / 1000

Question 4

If a Cisco ARC cluster is fully operational, how many replica copies does each shard have in addition to the leader replica?

  • A. 4
  • B. 3
  • C. 1
  • D. 2
Answer:

B

Discussions
0 / 1000

Question 5

Which two statements about tenant bridge domain Layer 2 unknown unicast forwarding modes are true'? (Choose two.)

  • A. If forwarding mode is flood, unknown Layer 2 unicast is sent to all Layer 2 ports in the bridge domain.
  • B. If forwarding mode is proxy, unknown Layer 2 unicast packets are sent to border leaf proxy for forwarding.
  • C. By default, multicast traffic is always flooded within the bridge domain VLAN.
  • D. Layer 2 unknown unicast can be set to flood or proxy, the default is flood.
  • E. If border leaf proxy cannot resolve the destination, packet is flooded.
Answer:

A B

Discussions
0 / 1000

Question 6

When you use a Cisco UCS fabric interconnect, which protocol must be configured between the fabric interconnect and the
ESX/ server?

  • A. PFC
  • B. vPC
  • C. HSRP
  • D. Cisco Discovery Protocol
Answer:

B

Discussions
0 / 1000

Question 7

At which point during VMM integration do you need to create the vDS switch within vCenter?

  • A. when starting up the VM
  • B. No need to create the vDS, the Cisco APIC controller does that automatically.
  • C. after assigning the EPG to the VMM controller
  • D. before defining the VLAN pool that is assigned to the VMM controller
Answer:

B

Discussions
0 / 1000

Question 8

In the Cisco APIC, how are fabric-wide unique identifiers managed?

  • A. dme
  • B. coop
  • C. eltmc
  • D. idmgr
Answer:

A

Discussions
0 / 1000

Question 9

Wh.ch two statements about the Cisco ACl distributed gateway are true? (Choose two.)

  • A. Endpoints attached to a leaf always find their gateway locally on the attached leaf.
  • B. The routing function of the SVl is performed on the leaf in the Northstar ASIC.
  • C. Endpoint mobility is restricted to a specific port on a specific leaf.
  • D. The routing function of the SVl is performed on the leaf in the Trident 2 Broadcom ASIC.
  • E. Gateway is represented as a SVl.
Answer:

B D

Discussions
0 / 1000

Question 10

Which MO name represents a physical domain?

  • A. RtDomP
  • C. physDomP
  • D. InfraRtDomP
Answer:

C

Discussions
0 / 1000

Question 11

During day-to-day operations, you notice that the HealthScore has decreased. What should you check first to understand
what has impacted the score?

  • A. faults
  • B. audit togs
  • C. events
  • D. accounting logs
Answer:

A

Discussions
0 / 1000

Question 12

Which packets are counted after the atomic counters are configured?

  • A. packets that are switched in the hypervisors
  • B. packets that are locally switched
  • C. packets that are switched via AVS
  • D. packets that traverse the fabric
Answer:

A

Discussions
0 / 1000

Question 13

Which statement about the default MAC address for the distributed gateway in the Cisco ACI Fabric is true?

  • A. There is no default MAC address.
  • B. A custom MAC address must be configured under each bridge domain.
  • C. The default MAC address is 00 11;BD:F9:88:0C.
  • D. The default MAC address is 00:22:BD:F8:19:FF.
Answer:

B

Discussions
0 / 1000

Question 14

Where does the VIP for the vPC come from?

  • A. assigned by Cisco ARC from the management tenant IP space.
  • B. allocated from the vPC domain number assigned to the vPC peers.
  • C. DHCP from the infra TEP pool leaf portion.
  • D. DHCP from the infra TEP pool VIP portion.
Answer:

D

Discussions
0 / 1000

Question 15

In the Cisco Nexus 9508 chassis, how many Broadcom T2 ASICs are on the fabric module?

  • A. 4
  • B. 1
  • C. 2
  • D. 0
Answer:

A

Discussions
0 / 1000
